Appendix B

B-10

Intel RAID

Degraded RAID Array

A RAID 1, RAID 5 or RAID 10 volume is reported as degraded when one of its hard

drive members fails or is temporarily disconnected, and data mirroring is lost. As a



re-establish data mirroring and restore data redundancy, refer to the procedure below

that corresponds to the current situation.

Missing Hard Drive Member

1. 

2. Reconnect the hard drive.

3. Reboot the system to Windows; the rebuild will occur automatically.

Failed Hard Drive Member

1. 

2. Replace the failed hard drive with a new one that is of equal or greater capacity.

3. Reboot the system to Intel RAID Option ROM by press <Ctrl> and <I> keys

simultaneously during the Power-On Self Test (POST).

4. Select the port of the destination disk for rebuilding, and then press ENTER.

RAID Volumes



0 Volume0 RAID 1(Mirror) N/A XXX.XGB Degraded Yes

Physical Disks:

    

1 XXXXXXXXXXXXX XXXXXXXXXXXXX XXX.XGB Member Disk (0)

2 XXXXXXXXXXXXX XXXXXXXXXXXXX XXX.XGB Member Disk (0)



DISK / VOLUME INFORMATION

[ ]

4. Recovery Volume Options

5. Exit

RAID Volumes :



Physical Devices :



1 XXXX-XXXXXXXX XXXXXXXXXXXXXX XXX.XGB Non-RAID Disk

2 XXXX-XXXXXXXX XXXXXXXXXXXXXX XXX.XGB Non-RAID Disk



1. Create RAID Volume

2. Delete RAID Volume

“Degraded” volume and disk available for rebuilding detected. Selecting

a disk initiates a rebuild. Rebuild completes in the operating system.

[ ]

DEGRADED VOLUME DETECTED

Select the port of the destination disk for rebuilding (ESC to exit):



   

1 XXXX-XXXXXXXX XXXXXXXXXXXXXX XXX.XGB

[ ]

MAIN MENU
